Passenger Elevator

• Capacity
• 1000 Kg

• Car Dimension
• 1500mm x 1500mm x 2000mm (customized)

• Control Device
• Other, PLC / Push Button

• Door Opening Size
• 900mm x 2000mm

• Drive Type
• Hydraulic

• Hoist Way Size
• 2000mm x 2000mm

• Inclination
• 0 (Vertical Lift)

• Load Capacity
• Up to 2000 Kg (customized)

• Machine Room Size
• 2500mm x 2000mm

• Material
• other Sheet, Mild Steel / Stainless Steel

• Max. Lifting Height
• 10 meters

• Max. Lifting Weight
• As per requirement (standard: 1000 Kg)

• Mechanism Type
• Other, Hydraulic

• Noise Level
• < 60 dB

• Overhead Height
• 2800mm

• Pit Depth
• 500mm

• Power Supply
• 3-phase, 50 Hz

• Safety Device
• Other, Overload protection, Emergency stop

• Speed
• 0.2 ~ 0.3 m/s

• Type
• Other, Goods Elevator

• Usage
• Other, Material Handling, Industrial Warehouses, Factories

• Voltage
• 220V / 380V

• Working Temperature
• -10C to 60C

• Capacity
• 4-6 Persons

• Car Dimension
• 1000mm x 1200mm (customizable)

• Control Device
• Other, Microcomputer PLC Control

• Door Opening Size
• 700mm - 800mm

• Drive Type
• Other, Traction Drive

• Hoist Way Size
• 1650mm x 1450mm

• Inclination
• 0 (Vertical lift)

• Load Capacity
• 320 kg - 630 kg

• Machine Room Size
• 1800mm x 1500mm

• Material
• other Sheet, Stainless Steel or Painted Steel

• Max. Lifting Height
• Up to 12 Floors (36 m)

• Max. Lifting Weight
• 630 Kg

• Mechanism Type
• Other, Traction

• Noise Level
• Below 60dB

• Overhead Height
• 4100 mm

• Pit Depth
• 1200 mm

• Power Supply
• 50Hz/60Hz

• Safety Device
• Other, Overload Protector, Emergency Alarm, Interlock Device

• Speed
• 0.4 - 1.0 m/s

• Type
• Other, MR (with Machine Room) / MRL (Machine Room Less)

• Usage
• Other, Residential Building

• Voltage
• 220V/380V

• Working Temperature
• -5C to 40C

• Capacity
• 8 to 20 Persons

• Car Dimension
• Customized as per requirement

• Control Device
• Other, Microcomputer Control (PLC)

• Door Opening Size
• 800 mm - 1100 mm

• Drive Type
• Other, VVVF Drive

• Hoist Way Size
• 1600 mm x 1700 mm (varies by capacity)

• Inclination
• 0 (Vertical Elevator)

• Load Capacity
• 630 kg - 1600 kg

• Machine Room Size
• 2000 mm x 2500 mm (varies by capacity)

• Material
• other Sheet, Stainless Steel / Mild Steel

• Max. Lifting Height
• Up to 48 Floors

• Max. Lifting Weight
• 1600 kg

• Mechanism Type
• Other, Gearless / Geared Traction

• Noise Level
• <65 dB

• Overhead Height
• 4200 mm

• Pit Depth
• 1500 mm - 1800 mm

• Power Supply
• 50/60 Hz

• Safety Device
• Other, Overload device, Emergency stop, Door locking device

• Speed
• 1.0 - 2.5 m/s

• Type
• Other, Automatic Commercial Passenger Elevator

• Usage
• Other, Commercial Building, Office, Shopping Mall

• Voltage
• 220V / 380V

• Working Temperature
• -10C to 55C

• Capacity
• 6-20 Persons

• Car Dimension
• Approx. 1100 x 2000 x 2300 mm

• Control Device
• Other, Microcomputer Control

• Door Opening Size
• 800-1100 mm

• Drive Type
• Other, VVVF Drive

• Hoist Way Size
• 1600 x 2200 mm or Customized

• Inclination
• 0 (Vertical)

• Load Capacity
• 450-1350 kg

• Machine Room Size
• 2200 x 3000 mm

• Material
• other Sheet, Stainless Steel, Glass Panel

• Max. Lifting Height
• Up to 60 m

• Max. Lifting Weight
• 1350 kg

• Mechanism Type
• Other, Traction

• Noise Level
• 50 dB

• Overhead Height
• 4200 mm

• Pit Depth
• 1500 mm

• Power Supply
• AC

• Safety Device
• Other, Overload Sensor, Emergency Stop, Door Lock

• Speed
• 1-2.5 m/s

• Type
• Other, Passenger Elevator

• Usage
• Other, Residential, Commercial Buildings, Hotels

• Voltage
• 380V

• Working Temperature
• -10C to 40C

• Capacity
• 4500-9000 persons/hour

• Car Dimension
• Customizable as per project requirement

• Control Device
• Other, Microcomputer (PLC) control

• Drive Type
• Other, AC gear motor

• Hoist Way Size
• As per standard escalator curve design

• Inclination
• 30 or 35

• Load Capacity
• 600 kg per step

• Machine Room Size
• Not required (machine room-less design)

• Material
• other Sheet, Stainless steel & toughened glass

• Max. Lifting Height
• 10-18 m

• Max. Lifting Weight
• 9000 kg

• Mechanism Type
• Other, Automated curved step mechanism

• Noise Level
• 65 dB

• Overhead Height
• As per installation site

• Pit Depth
• Standard 600-1000 mm

• Power Supply
• 3-phase, 50Hz/60Hz

• Safety Device
• Other, Multiple electronic and mechanical safety devices including emergency stop, step missing detection, handrail entry protection, safety switches, and anti-reversal protection

• Speed
• 0.5 m/s

• Step Width
• 600 mm / 800 mm

• Type
• Other, Round passenger escalator

• Usage
• Other, Shopping malls, airports, metro stations, commercial facilities

• Voltage
• 380V / 220V

• Working Temperature
• -10C to 45C

• Capacity
• 2-4 persons

• Car Dimension
• 1000 mm x 1000 mm

• Control Device
• Other, Microprocessor Controller

• Door Opening Size
• 700 mm

• Drive Type
• Hydraulic

• Hoist Way Size
• 1500 mm x 1450 mm

• Load Capacity
• 320 kg

• Machine Room Size
• Not required (Machine Roomless Design)

• Material
• other Sheet, Stainless Steel/Glass

• Max. Lifting Height
• Up to 12 meters

• Max. Lifting Weight
• Up to 350 kg

• Mechanism Type
• Other, Hydraulic

• Noise Level
• < 65 dB

• Overhead Height
• 3200 mm

• Pit Depth
• 350 mm

• Power Supply
• Electric

• Safety Device
• Other, Emergency Lowering, Door Lock, Overload Sensor

• Speed
• 0.3 - 0.5 m/s

• Type
• Other, Residential Hydraulic Elevator

• Usage
• Other, Residential

• Voltage
• 220-240V

• Working Temperature
• 5C to 40C
